FOAM EQUIPMENTS (BRANCH PIPE)
FOAM EQUIPMENTS
Foam Equipments are used in firefighting to deliver fire retardant foam for the purpose of extinguishing a fire or protecting unburned areas. Typical components include a water source, a centrifugal pump, foam concentrate tanks, a direct-injection foam proportioning system on the discharge side of the pump, a mixing chamber or device, a rotary air compressor, and control systems to ensure the correct mixture of concentrate, water, and air.
Technical Specification:
| Product Code No. | Description | Inlet Size's | Material of Construction | Performance (Test) |
|---|---|---|---|---|
| FB-013 FB-5X |
2½" (63mm) Male Instantaneous Inlet | 2½" (63mm) Male Instantaneous. | Aluminium IS:617 | Discharge Water : 225 LPM discharge at 7Kgf/cm' Jet Throw Range : 15 Mtr minimum. Foam Induction : Available with foam inductor. Working Pressure : 10Kgf/cm' Max. Foam Expansion : 8 to 10 times |
| FB-014 FB-10X |
2½" (63mm) Male Instantaneous Inlet | 2½" (63mm) Male Instantaneous. | Aluminium IS:617 | Discharge Water : 450 LPM discharge at 7Kgf/cm' Jet Throw Range : 22 Mtr minimum. Foam Induction : Available with foam inductor or without foam inductor Working Pressure : 10Kgf/cm' Max. Foam Expansion : 8 to 10 times |
